Engraving by Using Nose
Nose is a sub-component to support engraving along with the curved surface of material. Therefore, it is possible
to engrave on the curved surface of material with consistent depth by using the nose.
Be sure to release the engraver pressure lock. If you engrave with fixing head, the nose, tool and
materials may be damaged.
1. Replace the tool with V cut tool and conduct automatic measurement of tool length.
2. Turn the depth nose lock to left and loosen the bolt. Turn the nose height adjustment screw the left and lower it
down about 1~2mm.
