If engrave border is cancelled, a tool path will engrave only the inside of the
character created.
When moving to another engraving location, it is necessary to lift Z axis to
prevent the tool from contacting with the material surface before moving. For
this, designate the height to be applied at this time.
Designate a speed at which XY axis will move during the engraving.
Designate a speed at which Z axis will move during the engraving.
Designate hatching gap.
0.1mm 0.2mm 0.3mm
Designate a margin between object outline and tool path.
0.1mm 0.2mm 0.3mm
Only engraving option, direction and tool of the tool path are shown.
Transfer tool path window is displayed
