12.1.6.1 I Flag
The I flag enables or disables the maskable interrupt. Setting the I flag to 1 (enabled) enables the maskable
interrupt. Setting the I flag to 0 (disabled) disables all maskable interrupts.
12.1.6.2 IR Bit
The IR bit is set to 1 (interrupt requested) when an interrupt request is generated. Then, when the interrupt
request is acknowledged and the CPU branches to the corresponding interrupt vector, the IR bit is set to 0 (=
interrupt not requested).
The IR bit can be set to 0 by a program. Do not write 1 to this bit.
Operations of the IR bit vary by Timer RD interrupt, clock synchronous serial I/O interrupt with chip select or
I
2
C bus interface interrupt.
For details, refer to 12.5 Timer RD Interrupt, Clock Synchronous Serial I/O with Chip Select Interrupts
and I
2
C bus Interface Interrupts (Interrupts with Multiple Interrupt Request Sources).
12.1.6.3 Bits ILVL2 to ILVL0 and IPL
Interrupt priority levels can be set using the ILVL2 to ILVL0 bits.
Table 12.3 lists the Settings of Interrupt Priority Levels and Table 12.4 lists the Interrupt Priority Levels
Enabled by IPL.
The following are conditions under which an interrupt is acknowledged:
• I flag = 1
• IR bit = 1
• Interrupt priority level > IPL
The I flag, IR bit, ILVL2 to ILVL0 bits and IPL are independent of each other. They do not affect one another.
Table 12.3 Settings of Interrupt Priority
Levels
ILVL2 to ILVL0 Bits Interrupt Priority Level Priority Order
000b Level 0 (interrupt disabled)
−
001b Level 1 Low
010b Level 2
011b Level 3
100b Level 4
101b Level 5
110b Level 6
111b Level 7 High
Table 12.4 Interrupt Priority Levels Enabled by
IPL
IPL Enabled Interrupt Priority Levels
000b Interrupt level 1 and above
001b Interrupt level 2 and above
010b Interrupt level 3 and above
011b Interrupt level 4 and above
100b Interrupt level 5 and above
101b Interrupt level 6 and above
110b Interrupt level 7 and above
111b All maskable interrupts are disabled
