R8C/20 Group, R8C/21 Group 14. Timers
Rev.2.00 Aug 27, 2008 Page 187 of 458
REJ09B0250-0200
Figure 14.49 TRDPMR Register in Output Compare Function
Timer RD PWM Mode Register
Symbol Address After Reset
TRDPMR
0139h 10001000b
Bit Symbol Bit Name Function RW
b3 b2
—
(b3)
b1 b0
000
PWMB0
b7 b6 b5 b4
000
RW
PWMC0 RW
PWM mode of TRDIOB0 selection bit Set to 0 (timer mode) in the output
compare function
PWM mode of TRDIOC0 selection bit Set to 0 (timer mode) in the output
compare function
—
PWM mode of TRDIOB1 selection bit Set to 0 (timer mode) in the output
compare function
RW
RW
Nothing is assigned. If necessary, set to 0.
When read, the content is 1.
Set to 0 (timer mode) in the output
compare function
PWM mode of TRDIOD0 selection bit Set to 0 (timer mode) in the output
compare function
PWMD0 RW
—
(b7)
—
PWMB1
PWMC1 RW
Nothing is assigned. If necessary, set to 0.
When read, the content is 1.
PWM mode of TRDIOC1 selection bit Set to 0 (timer mode) in the output
compare function
PWMD1
PWM mode of TRDIOD1 selection bit
