C - 5
REVISION HISTORY R8C/20 Group, R8C/21 Group Hardware Manual
0.20 Jun 28, 2006 146 Table 14.8 Programmable Waveform Generation Mode Specifications,
“Write to Timer” in the item;
“TRAPRE” → “TRBPRE” corrected.
149 Table 14.9 Programmable One-Shot Generation Mode Specifications,
“Write to Timer” in the item;
“TRAPRE” → “TRBPRE” corrected.
153 Table 14.10 Programmable Wait One-Shot Generation Mode
Specifications, “Write to Timer” in the item;
“TRAPRE” → “TRBPRE” corrected.
157 Table 14.11 Timer RD Operation Clocks;
“TPSC2” → “TCK2” and “TRSC0” → “TCK0” revised.
On the 5th line below the Table 14.11;
“(Pin output ~ detection)” added.
158 to 160
Table 14.12 Pin Functions TRDIOA0/TRDCLK(P2_0)
Table 14.13 Pin Functions TRDIOB0(P2_1)
Table 14.14 Pin Functions TRDIOC0(P2_2)
Table 14.15 Pin Functions TRDIOD0(P2_3)
Table 14.16 Pin Functions TRDIOA1(P2_4)
Table 14.17 Pin Functions TRDIOB1(P2_5)
Table 14.18 Pin Functions TRDIOC1(P2_6)
Table 14.19 Pin Functions TRDIOD1(P2_7)
Table 14.20 Pin Functions INT0(P4_5) added.
162 14.3.1 Mode Selection deleted
Table 14.21 Count Source Selection;
Selection of f1, f2, f4, f8, f32, and fOCO40M revised.
Figure 14.29 Block Diagram of Count Source;
“TPSC2 to TPSC0” → “TCK2 to TCK0” revised.
163 Figure 14.30 Buffer Operation in Input Capture Function revised.
164 Figure 14.31 Buffer Operation in Output Compare Function revised.
On the 4th line below the Figure 14.31;
“IOC2 to IOC0 bits” → “IOC2 bit” and “IOA2 to IOA0 bits” → “IOA2 bit”
revised.
On the 7th line below the Figure 14.31;
“IOD2 to IOD0 bits” → “IOD2 bit” and “IOB2 to IOB0 bits” → “IOB2 bit”
revised.
On the 8th line below the Figure 14.31;
“Bits IMFC ~ capture function” added.
165 Below the Figure 14.32 Synchronous Operation;
“For the synchronous ~ register=110b)” deleted.
166 14.3.4 Pulse Output Forced Cutoff, on the 13th line;
“P2D” → “PD2” corrected.
On the 15th line;
“P4_5 bit in the P4D register” → “PD4_5 bit in the PD4 register”
corrected.
On the 2nd line from the bottom;
“According to ~ of interrupts” added.
Rev. Date
Description
Page Summary
