C - 6
REVISION HISTORY R8C/20 Group, R8C/21 Group Hardware Manual
0.20 Jun 28, 2006 168 14.3.5 Input Capture Function, on the 5th line;
“The TRDGRA0 register ~ trigger input.” added.
Figure 14.34 Block Diagram of Input Capture Function;
NOTES revised.
169 Table 14.23 Input Capture Function Specifications revised.
170 Figure 14.35 Registers TRDSTR and TRDMR in Input Capture Function;
The TRDSTR register revised.
171 Figure 14.36 TRDPMR Register in Input Capture Function revised.
172 Figure 14.37 TRDFCR Register in Input Capture Function revised.
174 Figure 14.39 Registers TRDCR0 to TRDCR1 in Input Capture Function
revised.
175 Figure 14.40 Registers TRDIORA0 to TRDIORA1 in Input Capture
Function revised.
176 Figure 14.41 Registers TRDIORC0 to TRDIORC1 in Input Capture
Function revised.
177 Figure 14.42 Registers TRDSR0 to TRDSR1 in Input Capture Function
revised.
183 Table 14.25 Output Compare Function Specifications, on the 5 to 6th
lines from the bottom;
“TRCIOAi” → “TRDIOAi” and “TRCIOBi” → “TRDIOBi” corrected.
184 Figure 14.49 Registers TRDSTR and TRDMR in Output Compare
Function revised.
185 Figure 14.50 TRDPMR Register in Output Compare Function revised.
186 Figure 14.51 TRDFCR Register in Output Compare Function revised.
187 Figure 14.52 Registers TRDOER1 to TRDOER2 in Output Compare
Function;
NOTE in the TRDOER2 register added.
189 Figure 14.54 Registers TRDCR0 to TRDCR1 in Output Compare
Function revised.
190 Figure 14.55 Registers TRDIORA0 to TRDIORA1 in Output Compare
Function revised.
191 Figure 14.56 Registers TRDIORC0 to TRDIORC1 in Output Compare
Function revised.
192 Figure 14.57 Registers TRDSR0 to TRDSR1 in Output Compare
Function revised.
200 Figure 14.65 TRDSTR Register in PWM Mode revised
201 Figure 14.66 Registers TRDMR and TRDPMR in PWM Mode revised
202 Figure 14.67 TRDFCR Register in PWM Mode revised
203 Figure 14.68 Registers TRDOER1 to TRDOER2 in PWM Mode;
NOTE in the TRDOER2 register added.
204 Figure 14.69 Registers TRDOCR and TRDCR0 to TRDCR1 in PWM
Mode revised.
Rev. Date
Description
Page Summary
