User Manual Bearing System RT-300
Issue: 2017/06/27 [Rev 1.04.c] Page 28 of 79 12-9-1-0013-9-2-0001-3-1-60
6 The Menu
Adjustments and also system configurations, which have not to be changed during bearing
operations, are to be selected and adjusted in the menu. Further information’s as serial
numbers or software versions are available.
- Key 7 < Menu > calls up the main menu on the LC-display.
- Using keys 3 < >, 5 < >, 8 < >, and 10 < > navigating in the corresponding submenu.
The selected menu subjects are shown inverted (highlighted).
- Key 6 < Ok > will confirm the selection.
- Pressing key 9 < Esc > will reject the new selection and the device will return to the next
higher menu level, or in the main menu, the device will leave the menu function.
- If the menu is called up and key 7 < Menu > is pressed, the device will return to the bearing
mode. Changed adjustments will be rejected.
For better orientation the LC-display´s top line is showing the present position in the menu.
ATTENTION
Wrong adjustments may affect the bearing system`s functions seriously. Alarm
and bearing functions may not work as desired or may deliver faulty values if the
system is wrong adjusted. It is important before starting to adjust, to know what to
do. Therefore, please read this operating manual carefully in advance. In case of
arising questions, please contact our service. We will support you gladly.
