User Manual Bearing System RT-300
Issue: 2017/06/27 [Rev 1.04.c] Page 76 of 79 12-9-1-0013-9-2-0001-3-1-60
Pos Menu Action Default See
chapter.
Remarks
- LAST TIME if factory default is not
optimal.
12 Activating heading compensation
for repeat function
- LAST VALUE COMPENSATION
OFF 6.2.1.5.1.6 Only possible, if external or
internal compass is available.
13 RECEIVER Selecting frequency mode in
maritime band
- CHANNEL MODE
ON 6.2.1.5.2.1 Default setup reasonable, for
frequency tuning in maritime
band usually by entering
channel number.
14 Selecting starting setup
(POWER ON DEFAULTS)
ON 6.2.1.5.2.2 If the device is to restart with
last tuned frequency / channel
number the setting “OFF” has
to be selected.
15 SERIAL Selection of serial interface for data
reception
- RS-232
- NMEA (RS-422)
- RS-485
RS-232 6.2.1.5.3.1 Required only, if external
devices connected.
Adjustments are depending
on connected device.
16 Adjusting data transmitting velocity
(BAUD RATE)
4800
Baud
6.2.1.5.3.2
17 Adjusting device addressing
(IDENTITY)
000 6.2.1.5.3.3
18 Selecting type of transmission
(TALK MODE)
AUTO 6.2.1.5.3.5
19 Adjusting transmitting interval
(in auto-talk-mode) (TALK TIME)
250 ms 6.2.1.5.3.6
20 COMPASS Selecting data source for reference
direction true north
(TRUE SOURCE)
NMEA
XXHDT
6.2.1.5.4.1
21 Selecting reference direction for
magnetic north
(MAG SOURCE)
NMEA
XXHDT
6.2.1.5.4.2
