Replacing the Master Roll
131
4
•
8: Insert the master roll.
Note
❒
Make sure the leading edge reaches the in-
terior of the m
aster holder.
•
9: Close the master guide.
•
10: Push in the master tray until it stops.
ACY044S
ACY045S
ACY046S
ACY047S
