Ricoh 3590DNP - Zoom

Printing Functions
60
3
A Place the originals.
B Press [Reduce / Enlarge].
Note
❒ To select a preset ratio on the
initial display, press the short-
cut Reduce/Enlarge key, and
then proceed to step
E
.
C Press [Enlarge] or [Reduce].
D Select a ratio, and then press [OK].
E Press the {Start} key.
-Create margin mode
Use Create Margin to reduce the im-
age to 93% of its original size with the
center as reference. You can assign
this function to a shortcut key on the
initial display. By combining it with
the Reduce / Enlarge function, you
can also provide the Reduce / En-
large print with a margin.
Reference
Related initial settings
p.161 “Ratio for Create Margin”
p.163 “Function Key:F1–5”
Zoom
You can change the reproduction ra-
tio in increments of 1%.
Note
❒ You can select a preset ratio close
to the ratio using [Reduce] or [En-
large], and then adjust it further,
using [n] or [o].
A Place the originals.
B Press [Reduce / Enlarge].
