• Connect the printer to the network in advance and switch it on.
•
Specify the printer's IP address on its control panel in advance.
1. On the [Apple] menu, click [System Preferences...], and then click the [Print & Fax] in the
[System Preferences] dialog box.
The [Print & Fax] appears.
Under Mac OS X 10.3.x - 10.4.x, double-click the Printer Setup Utility icon in the [Utilities] folder in
the [Applications] folder.
The [Printer List] appears.
2. Click [
].
The add printer screen appears.
Under
Mac OS X 10.3.x - 10.4.x, click [Add Printer...] on the [Printers] menu or [Add] on the toolbar.
The [Printer Browser] appears.
3. On the add printer screen, click [IP].
Under Mac OS X 10.3.x - 10.4.x, click [IP Printer] in the [Printer Browser] dialog box.
4. From the [Protocol] pop-up menu, select [Line Printer Daemon - LPD].
You can also select [HP Jetdirect - Socket].
5. In the [Address:] field, enter the IP address of the printer you want to use.
6. Select [Select a driver to use...] in the [Print Using] field, and then select a printer in the list.
Under Mac OS X 10.3.x - 10.4.x, select [RICOH] in the [Printer Using] field, and then select a printer
in the [Model Name] list.
7. Click [Add].
8. If you want to use the bypass tray, select options in the [Installable Options] dialog box,
and then select [Continue].
9. The IP address of the registered printer appears in [Print & Fax].
Under Mac OS X 10.3.x - 10.4.x, the IP address of the registered printer appears in [Printer List].
10. On the [System Preferences] menu, click [Quit System Preferences].
The [System Preferences] closes.
Under Mac OS X 10.3.x - 10.4.x, click [Quit Printer Setup Utility] on the [Printer Setup Utility] menu.
The [Printer Setup Utility] closes.
• To make fine adjustments to print quality, set [Adjust Color Density...] before using the printer.
•
If printing is too slow with protocol [LPD (Line Printer Daemon)], select protocol [HP Jetdirect -
Socket].
5. Using the Printer with a Macintosh
136
