• p.220 "Paper Is Not Fed or Delivered Normally"
•
p.32 "Detaching and Reattaching the Multi Bypass Tray"
Removing Paper Jammed in the Duplex Unit
Follow the procedure below to remove paper jammed in the duplex unit.
The GX e2600 is not equipped with a duplex unit.
• Make sure the duplex unit is attached properly.
•
If the bypass tray is attached to the printer, switch the printer off and detach the bypass tray.
You can feed the jammed paper to output ramp by opening the left cover and turning the paper feed wheel.
If turning the paper wheel does not remove the jammed paper, use the following procedure to remove it:
1. Press the duplex unit cover button at the center of the bypass tray, and then open the duplex
unit cover.
To Next Page
