A test pattern to adjust the print start position is printed.
8. Check the optimal adjustment values on the printed test pattern.
9. Fold the test pattern sheet in half lengthwise.
10. The
optimal adjustment value is the difference between the single vertical line and the cross's
vertical line that you can see when the folded paper is held up to light. When the difference
is one calibration mark in the "+" direction, the optimal adjustment value for the [Read
Direction] is "+1.0".
11. Fold the test pattern sheet in half widthwise, and then check the adjustment value for the
[Feed Direction]
Adjustment values are in 0.1 increments.
12. Press the [ ] or [ ] key to display [Adjustment], and then press the [#Enter] key.
Registration:
Adjustment
13. Press the [ ] or [ ] key to select a paper tray, and then press the [#Enter] key.
Adjustment:
Tray 1
6. Maintaining
172
