Ricoh Aficio GX e3300N

1. Close the cover.
Top cover
BUG182S
Left cover
BUG156S
Duplex unit cover
BUG159S
If the bypass tray is attached to the printer, switch the printer off and detach the bypass tray.
Check that the duplex unit is correctly attached and the duplex unit cover is closed.
• There is a guide board in the recess behind the duplex unit. If the guide board is open, close it.
7. Troubleshooting
268
7
