Power Source:
Taiwan: 110 V, 60 Hz, 12 A
Korea: 220 V, 60 Hz, 7 A
North and South America: 120 V, 60 Hz, 12 A
Europe, Asia: 220 – 240 V, 50/60 Hz, 7 A
Power Consumption:
Full System: Not above 1.28 kW
Off Mode (GDI): Not above 10 W
Off Mode (Basic): Not above 1 W
• Full system - Maximum possible power consumption (any
combination of mainframe and options), excluding optional
heaters, key counter, fax unit, and printer controller.
Noise Emission:
Standby (Mainframe/Full system): Not above 40 dB(A)
Operating (Mainframe only): Not above 62 dB(A)
Operating (Full System): Not above 66 dB(A)
• The above measurements were made in accordance with ISO
7779. Measurements were taken from the normal position of the
operator.
Dimensions (W x D x H):
B245/B276/B268: 550 x 568 x 420 mm (21.7" x 22.4" x 16.5")
B269/B277: 587 x 568 x 558 mm (23.1" x 22.4" x 23.0")
Measurement Conditions
1.
With bypass feed table closed
2.
Without the A(R)DF
Weight:
B245: 35 kg (78 lb.)
B268/B276: 44 kg (96 lb.)
B269/B277: 47 kg (103 lb.)
(Excluding A(R)DF, platen cover, toner, and developer)
Copying Speed in Multicopy Mode (copies/minute):
1. Appendix: Specifications
4
