EM 60k 120k AN NOTE
Cleaning brush (charge roller) R
Cleaning blade (OPC drum) R
Pick-off pawls (OPC drum) R
Transfer roller R
ID sensor C C Blower brush
Paper Feed
EM 60k 120k AN NOTE
Paper feed roller (each tray) C R C Clean with water or alcohol.
Friction pad (each tray) C R C Clean with water or alcohol.
Bottom-plate pad (each tray) C C Clean with water or alcohol.
Paper feed roller (bypass tray) C C Clean with water or alcohol.
Friction pad (bypass tray) C C Clean with water or alcohol.
Bottom-plate pad (by-pass tray) C C Clean with water or alcohol.
Registration rollers C C Clean with water or alcohol.
Relay rollers C C Clean with water or alcohol.
Paper feed guides C C Clean with water or alcohol.
Paper-dust Mylar C C Clean with water or alcohol.
Fusing Unit
EM 60k 120k AN NOTE
Hot roller R
Pressure roller R
Pressure roller cleaning roller R
Hot roller bushings I
Pressure-roller bushing R
2. Appendix: Preventive Maintenance
18
