Bit Switches - 4
D418 116 SM
G3 Switch 05 (SP No. 1-105-006)
No Function Comments
Other settings - Not used
Initial modem type for 9.6 k or 7.2 kbps.
Bit 5 Bit 4 Setting
0 0 V.29
0 1 V.17
1 0 V.34
4-5
1 1 Not used
These bits set the initial modem type for
9.6 and 7.2 kbps, if the initial modem rate
is set at these speeds.
6-7 Not used Do not change the settings.
G3 Switch 06 (SP No. 1-105-007)
No Function Comments
Initial Rx modem rate(kbps)
Bit 3 Bit 2 Bit 1 Bit 0 kbps
0 0 0 1 2.4
0 0 1 0 4.8
0 0 1 1 7.2
0 1 0 0 9.6
0 1 0 1 12.0
0 1 1 0 14.4
0 1 1 1 16.8
1 0 0 0 19.2
0-3
1 0 0 1 21.6
These bits set the initial starting modem
rate for reception.
Use a lower setting if high speeds pose
problems during reception.
If a modem rate 14.4 kbps or slower is
selected, V.8 protocol should be
disabled manually.
Cross reference
V.8 protocol on/off - G3 switch 03, bit2
