Service Call Conditions
D062/D063/D065/D066 3-48 SM Appendix
disconnected, defective
2nd Stopper Motor Error Multi Folder (D454)
The 2nd stopper HP sensor did not detect the 2nd stopper in (or out of)
its home position within the prescribed time. The 1st occurrence causes
a jam, and the 2nd occurrence causes this SC code.
783-1 B
2nd stopper HP sensor dirty
Sensor harness or connector loose, broken, defective
2nd stopper motor harness or connector loose, broken, defective
Sensor defective
Motor or motor drive board defective
3rd Stopper Motor Error Multi Folder (D454)
The 3rd stopper HP sensor did not detect the 3rd stopper in (or out of)
its home position within the prescribed time. The 1st occurrence causes
a jam, and the 2nd occurrence causes this SC code.
783-2 B
3rd stopper HP sensor dirty
Sensor harness or connector loose, broken, defective
3rd stopper motor harness or connector loose, broken, defective
Sensor defective
Motor or motor drive board defective
1st Fold Motor Error Multi Folder (D454)
The motor drive PCB detected an error at the motor.
783-3 B
Motor harness or connector loose, broken, defective
Motor or motor drive board defective
2nd Fold Motor Error Multi Folder (D454)
783-4 B
The motor drive PCB detected an error at the motor.
