Service Call Conditions
D062/D063/D065/D066 3-50 SM Appendix
Registration Roller Release Motor Error Multi Folder (D454)
The registration roller HP sensor did not detect the registration roller in
(or out of) its home position within the prescribed time. The 1st
occurrence causes a jam, and the 2nd occurrence causes this SC
code.
783-9 B
Registration roller HP sensor dirty
Sensor harness or connector loose, broken, defective
Registration roller release motor harness or connector loose,
broken, defective
Sensor defective
Motor or motor drive board defective
Fold Plate Motor Error Multi Folder (D454)
The fold plate HP sensor did not detect the fold plate in (or out of) its
home position within the prescribed time. The 1st occurrence causes a
jam, and the 2nd occurrence causes this SC code.
783-10 B
Fold plate HP sensor dirty
Sensor harness or connector loose, broken, defective
Fold plate motor harness or connector loose, broken, defective
Sensor defective
Motor or motor drive board defective
Jogger Fence Motor Multi Folder (D454)
The jogger fence HP sensor did not detect the jogger fence in (or out
of) its home position within the prescribed time. The 1st occurrence
causes a jam, and the 2nd occurrence causes this SC code.
783-11 B
Jogger fence HP sensor dirty
Sensor harness or connector loose, broken, defective
Jogger fence motor harness or connector loose, broken, defective
Sensor defective
Motor or motor drive board defective
