1. ADF
Lower the ADF over originals placed on the exposure glass.
If you load a stack of originals in the ADF, the ADF will automatically feed the originals one by one.
2. Exposure glass
Place originals face down here.
3.
Control panel
See p.36 "Guide to the Names and Functions of the Machine's Control Panel".
4. Front cover
Open to access the inside of the machine.
5. Paper tray
Load paper here.
6. Paper tray unit (Tray 2 and Tray 3)
Load paper here.
7. Ventilation holes
Prevent overheating.
8. Main power switch
To operate the machine, the main power switch must be on. If it is off, turn the switch on.
9. Bypass tray
Use to copy or print on OHP transparencies and label paper (adhesive labels).
10. Extender
Pull this extender out when loading A4
, 8
1
/
2
× 11 or larger size paper in the bypass tray.
11. Paper guides
When loading paper in the bypass tray, align the paper guides flush against the paper.
12.
Lower right cover
Open this cover when a paper jam occurs.
13. Right cover
Open this cover to remove jammed paper fed from the paper tray.
2. Getting Started
28
