Front and left view
CMR602
1
2
3
1. Internal tray guide
Open out and raise the end fence to support large paper.
2. Extenders
Raise these extenders to support large paper.
3.
Internal tray
Copied/printed paper and fax messages are delivered here.
Rear and left view
CMR634
1
1. Ventilation holes
Prevent overheating.
Guide to Names and Functions of Components
