Dial Pulse Type
Sets the number of pulses generated during dialing.
• N. (Default) Dialed "0" generates 10 pulses, "9" generates
9 pulses.
• N+1. Dialed "0" generates 1 pulse, "9" generates 10
pulses.
• 10-N. Dialed "0" generates 10 pulses, "9" generates 1
pulse.
Tone Signal Settings
Tone Signal Transmission Time Length
Sets the time length tone signal transmission. Default:
100 ms
Minimum Pause in Tone Dialing
Sets the minimum pause during tone dialing.
•
Default: 100 ms
•
Range: 100, 150,200 ms
DTMF Level
Dual tone output level High.
• -2dBm
•
-3dBm to -6dBm
• -7dBm (Default)
• -8dBm to -16dBm
• -17dBm
DTMF Delta
Sets the difference in the level between high and low
band frequency signals DTMF tones are sent.
• 2 dBm (Default)
•
3 dBM
1 Dial Tone Detection
Wait Time
The machine starts dialing after the time below has
expired without detecting a dial tone after dial toner
detection has been set for "No detection".
• Default: 3.5 sec.
•
Range: 3.5 to 14.0 sec.
Utilities
193
