Ricoh D037 - Copy Data Security Unit Type F (B829); Installation

Copy Data Security Unit Type F (B829)
SM 2-71 D037/D038/D040/D041
Installaion
2.18 COPY DATA SECURITY UNIT TYPE F (B829)
2.18.1 INSTALLATION
 Unplug the main machine power cord before you do the following procedure.
1. Remove the rear lower cover [A] of the machine ( x 5).
2. Remove the rear cover [B] of the machine ( x 7)
3. Scanner cable bracket [A] ( x 4)
4. Loosen the eight screws, and slide up the controller box cover [B].
