Exterior Covers
D037/D038/D040/D041 4-16 SM
3. Release the belt [A].
4. Front door [A] ( x 2, pin x 2)
4.4.3 ITB CLEANING UNIT COVER
1. Open the ITB cleaning unit cover [A] ( x 2).
