Ricoh D037 - Output Check Table

System Service Mode
D037/D038/D040/D041 9-346 SM Appendix
11" x 81/2" LEF*
3
(A4 LEF)
A4 LEF*
3
(11" x 81/2" LEF)
1 1 0 1
10.5" x 7.25" LEF*
4
(B5 LEF)
B5 LEF*
4
(10.5" x 7.25" LEF)
1 0 1 0
A5 LEF A5 LEF 0 1 0 0
A5 SEF A5 SEF 1 1 0 1
*1: The machine detects either 11" x 17" SEF or A3 SEF, depending on the setting of SP
5-181-010 (Tray 3) or SP 5-181-014 (Tray 4).
*2: The machine detects either 8.5" x 14" SEF or B4 SEF, depending on the setting of SP
5-181-011 (Tray 3) or SP 5-181-015 (Tray 4).
*3: The machine detects either 11" x 81/2" LEF or A4 LEF, depending on the setting of SP
5-181-009 (Tray 3) or SP 5-181-013 (Tray 4).
*4: The machine detects either B5 LEF or 10.5" x 7.25" LEF, depending on the setting of SP
5-181-012 (Tray 3) or SP 5-181-016 (Tray 4).
Table 5: Area Display
The bit 0 of these SPs shows the punch unit type.
2: 2 Holes, 2/3: 2/3 Holes, 4 (EU): 4 Holes Europe,
4 (Scan.): 4 Holes Scandinavia
SP 2 2/3 4 (EU) 4 (Scan.)
6120-013 Punch Unit:Area Detect2 0 0 1 1
6120-014 Punch Unit:Area Detect2 0 1 0 1
9.1.3 OUTPUT CHECK TABLE
Copier
5804 Display Description
5804 1 Paper Feed M1:CW:190mm/s -
5804 2 Paper Feed M1:CW:120mm/s -
