Ricoh D037 - Ardf (D366); Component Check; Installation Procedure

ARDF (D366)
SM 2-29 D037/D038/D040/D041
Installaion
2.7 ARDF (D366)
2.7.1 COMPONENT CHECK
Check the quantity and condition of the components against the following list.
No. Description Q’ty
1 ARDF 1
2 Stamp Cartridge 1
3 Knob Screw 2
4 Stud Screw 2
5 Attention Decal – Top Cover 1
2.7.2 INSTALLATION PROCEDURE
 Unplug the copier power cord before starting the following procedure.
1. Remove all tapes and shipping retainers.
