Punch Unit (D390)
D037/D038/D040/D041 2-48 SM
2.13 PUNCH UNIT (D390)
2.13.1 COMPONENT CHECK
Check the quantity and condition of the components against the following list.
No. Description Q’ty
1 Punch Unit 1
2 Output Tray Lower Cover 1
3 Drawer Connector 1
4 Bracket 1
5 Left Frame Cover 1
6 Punch Cover 1
2.13.2 INSTALLATION PROCEDURE
If the internal finisher has not already been installed, skip the ‘Removing the Internal
Finisher’ section, and go to the ‘Preparing the Punch Unit before Installing the Internal
