System Service Mode
SM Appendix 9-183 D037/D038/D040/D041
Appendix:
SP Mode
Tables
4806 [Carriage Move]
001 - -
Moves the carriage from the scanner home
position.
Dust may fall through the DF exposure
glass. Therefore, do this SP when you
transport the machine a long distance.
4807 [SBU Test Pattern Change]
001 - -
[0 to 255 / 0 / 1 /step]
4808 [Factory Setting Input]
002 Execution Flag -
[0 or 1 / 0 / 1 /step]
[ACC Data Display]
4902
This SP outputs the final data read at the end of ACC execution.
A zero is returned if there was an error reading the data.
[0 to 255 / 0 / 1 /step]
001 R DATA1 *ENG Photo C Patch Level 1 (8-bit)
002 G DATA1 *ENG Photo M Patch Level 1 (8-bit)
003 B DATA1 *ENG Photo Y Patch Level 1 (8-bit)
004 R DATA2 *ENG Photo C Patch Level 17 (8-bit)
005 G DATA2 *ENG Photo M Patch Level 17(8-bit)
006 B DATA2 *ENG Photo Y Patch Level 17 (8-bit)
4904 [IPU Board Test]
001
Test1 - Bit0: TAURUS register
