Ricoh D037 - Page 723

System Service Mode
SM Appendix 9-189 D037/D038/D040/D041
Appendix:
SP Mode
Tables
5062 [Parts PM System Setting]
Display or does not display the PM part yield on the LCD.
001 PCU:Bk *CTL
[0 or 1 / 1 / - ]
0: Not display, 1: Display
002 PCU:M *CTL
003 PCU:C *CTL
004 PCU:Y *CTL
005 Dev Unit:Bk *CTL
006 Dev Unit:M *CTL
007 Dev Unit:C *CTL
008 Dev Unit:Y *CTL
009 Fusing Unit *CTL
010 Fusing Roller *CTL
011 Fusing Belt *CTL
012
PCU Toner Collection
Bottle
*CTL
5066
[Parts PM Menu Display Setting]
Display or does not display the “PM parts” button on the LCD.
001 - *CTL
[0 or 1 / 1 / - ]
0: Not display, 1: Display
5067
[Parts PM System Setting]
Selects the service maintenance or user maintenance for each PM parts.
If the user service is selected, PM alert is displayed on the LCD.
001 PCU:Bk *CTL
[0: Service] or [1: User]
002 PCU:M *CTL
003 PCU:C *CTL
004 PCU:Y *CTL
005 Dev Unit:Bk *CTL
[0: Service] or [1: User]
006 Dev Unit:M *CTL
Rev. 07/15/2010
