Punch Unit PU3060
D146/D147/D148/D149/D150 2-96 SM
5. Attach the punch unit stay [A]. ( ×4)
Rear Front
6. Attach the punch waste paper guide [A]. (
×1)
§ After inserting the front tab of the punch waste paper guide into the frame [B] of the
finisher, insert the rear tab into the frame [C].
