PS3 Card Type M4/M3

SM 2-185 D146/D147/D148/D149/D150

Installation

2.36 PS3 CARD TYPE M4/M3

M4: D148/D149/D150, M3: D146/D147:

2.36.1 ACCESSORY CHECK

No. Description Q’ty

1 SD Card 1

2.36.2 INSTALLATION PROCEDURE

1. SD card slot covers [A] [B]( ×1)

D148/D149/D150:
