1.Detailed Descriptions
19
No. Description
1 Stapler Rotation Motor
Stapling Z-folded Paper
The top fence moves before the transferred paper is stacked.
The stack stopper moves to the location that is suitable for the size.
The leading edge of Z-folded paper bumps against the stack stopper.
The positioning roller drops the paper and it is stacked.
