Ricoh SR5050 - PSU and Related Components

Punch Unit PCB
Preparation
• Rear upper cover (page 15)
• Rear lower cover (page 16)
1. Remove the punch unit PCB ( x6, x4).
Shift Tray Jogger Unit PCB
Preparation
• Shift tray jogger unit (page 74)
1. Lay the shift jogger unit [A] on a flat surface.
2. Disconnect motor [B]. ( x1)
Boards
161
