Ricoh SR5050 - Drag Roller Unit

Re-installation
1. When you re-attach the exit roller cover [A]:
• Make sure the small mylar is set as shown.
• Make sure the large mylars and are set as shown.
Drag Roller Unit
Preparation
• End fence page 33
1. This is the drag roller unit [A].
Common Procedures
41
