4. Turn the bracket over and remove the motor [A] ( x2, x1)
Shift Tray HP Sensors (Front, Rear)
These sensors are mounted on the same bracket as the shift motor.
Preparation
• Remove end fence (page 33)
1. Remove sensor bracket [A] ( x1).
2. Remove sensors ( x2, x3, x 5 each)
1. Replacement and Adjustment
64
