Symbol What it means
Shoulder screw (black)
Spring
Standoff
Stud screw
Tapping screw (for plastic)
Timing belt
Washer
The notations "SEF" and "LEF" describe the direction of paper feed. The arrows indicate the direction of
paper feed.
In this manual "Main Scan" means "Horizontal" and "Sub Scan" means "Vertical", both relative to the
direction of paper feed.
