RIGOL Chapter 14 System Function Setting
14-6 MSO4000/DS4000 User’s Guide
Tip
The formats of the IP address, subnet mask, gateway address and DNS server
address are all “nnn.nnn.nnn.nnn” which consists of 4 groups of nnn separated by
“.”.
Network Parameter Setting Method:
1) Press the corresponding menu softkey to select the network parameter item to
be set (by default, the first item in the address is selected).
2) Turn the multi-function knob
to adjust the value of the item currently
selected.
3) Press the multi-function knob
to confirm the current item and select the
next item.
4) Repeat steps 2) and 3) until finishing the setting.
3. Set the DNS server address (when Auto IP or Static IP configuration
type is valid)
The format of the DNS server address is nnn.nnn.nnn.nnn; wherein, the range
of the first nnn is from 1 to 223 (except 127) and the ranges of the other three
nnn are from 0 to 255. You are recommended to ask your network administrator
for a DNS server address available.
press DNS and turn the multi-function knob to input the desired DNS server
address (for the setting method, refer to “Network Parameter Setting
Method”). Generally, users do not need to set the DNS server address;
therefore this parameter setting can be ignored.
4. Set the IP address (when Static IP configuration type is valid)
The format of IP address is nnn.nnn.nnn.nnn; wherein, the range of the first
nnn is from 1 to 223 (except 127) and the ranges of the other three nnn are
from 0 to 255. You are recommended to ask your network administrator for an
IP address available.
Press IP Address and turn the multi-function knob to input the desired IP
address (for the setting method, refer to “Network Parameter Setting
Method”). This setting will be saved in the non-volatile memory and if
