Trigger
Trigger Level
Range
CH1 to CH4: ±6 divs from center of the screen
EXT: ±0.8 V
Trigger Mode Auto, Normal, Single
Holdoff Range 100 ns to 10 s
High Frequency
Rejection
[1]
50 kHz
Low Frequency
Rejection
[1]
5 kHz
Edge Trigger
Edge Type Rising, Falling, Rising&Falling
Pulse Trigger
Pulse Condition Positive Pulse Width (greater than, lower than, within
specific interval);
Negative Pulse Width (greater than, lower than, within
specific interval)
Pulse Width Range 4 ns to 4 s
Runt Trigger
Pulse Polarity Positive, Negative
Qualifier None, >, <, <>
Pulse Width Range 4 ns to 4 s
Nth Edge Trigger
Edge Type Rising, Falling
Idle Time 40 ns to 1 s
Number of Edges 1 to 65535
Slope Trigger
Slope Condition Positive Slope (greater than, lower than, within specific
interval);
Negative Slope (greater than, lower than, within specific
interval)
Time Setting 10 ns to 1 s
Video Trigger
Polarity Positive, Negative
Synchrony All Lines, Line Num, Odd Field, Even Field
Signal Standard NTSC, PAL/ECAM, 480P, 576P, 720P, 1080P and 1080I
