Pattern Trigger
Pattern Setting H, L, X, Rising Edge, Falling Edge
RS232/UART Trigger
Polarity Normal, Invert
Trigger Condition Start, Error, Check Error, Data
Baud 2400 bps, 4800 bps, 9600 bps, 19200 bps, 38400 bps, 57600
bps, 115200 bps, 230400 bps, 460800 bps, 921600 bps,
1Mbps, User
Data Bits 5 bits, 6 bits, 7 bits, 8 bits
I2C Trigger
Trigger Condition Start, Restart, Stop, Missing ACK, Address, Data, A&D
Address Bits 7 bits, 8 bits, 10 bits
Address Range 0 to 127, o to 255, 0 to 1023
Byte Length 1 to 5
SPI Trigger
Trigger Condition CS (Chip Select), Timeout
Timeout Value 100 ns to 1 s
Data Bits 4 bits to 32 bits
Data Line Setting H, L, X
Clock Edge Rising Edge, Falling Edge
CAN Trigger
Signal Type Rx, Tx, CAN_H, CAN_L, Differential
Trigger Condition SOF, EOF, Frame Type, Frame Error
Baud 10 kbps, 20 kbps, 33.3 kbps, 50 kbps, 62.5 kbps, 83.3 kbps,
100 kbps, 125 kbps, 250 kbps, 500 kbps, 800 kbps, 1 Mbps,
User
Sample Point 5% to 95%
Frame Type Data, Remote, Error, OverLoad
Error Frame Type Bit Fill, Answer Error, Check Error, Format Error, Random
Error
FlexRay Trigger
Baud 2.5 Mb/s, 5 Mb/s, 10 Mb/s
Trigger Condition Frame, Symbol, Error, TSS
USB Trigger
Signal Speed Low Speed, Full Speed
Trigger condition SOP, EOP, RC, Suspend, Exit Suspend
