Rigol DS4024 - Measurement Specifications

RIGOL Chapter 17 Specifications
17-8 MSO4000/DS4000 User’s Guide
Measure
Cursor
Manual Mode: voltage deviation between cursors (△V), time
deviation between cursors (△T), reciprocal of △T (Hz)
(1 /△ T )
Track Mode: voltage and time values of the waveform point
Auto Mode: allow to display cursors during auto
measurement
Auto Measurement
Analog channel:
Measurements of Maximum, Minimum, Peak-Peak Value, Top
Value, Bottom Value, Amplitude, Average, Vrms–N, Vrms-1,
Overshoot, Pre-shoot, Area, Period Area, Period, Frequency,
Rise Time, Fall Time, Positive Pulse Width, Negative Pulse
Width, Positive Duty Cycle, Negative Duty Cycle, Delay
A
B , Delay A B , Delay A B , Delay A B ,
Phase A
B , Phase A B , Phase A B , Phase
A
B
Digital channel:
Frequency, Period, Positive Pulse Width, Negative Pulse
Width, Positive Duty Cycle, Negative Duty Cycle, Delay
A
B , Delay A B , Delay A B , Delay A B ,
Phase A
B , Phase A B , Phase A B , Phase
A
B
Number of
Measurements
Display 5 measurements at the same time.
Measurement
Range
Screen region, cursor region
Statistic Mode Extremum, difference
Measurement
Statistic
average, max, min, standard deviation, number of
measurements
Frequency Counter Hardware 6 bits frequency counter
(channels are selectable)
