Rinstrum C530 User Manual

No. of parameters 6
Save changes With TDD1
Increment Trade Counter No
Parameter Details
Parameter Description Range Default
1 Jog on time (milliseconds) 100 .. 60000 100
2 Jog off time (milliseconds) 100 .. 60000 100
3 Jogs in set 1 .. 20 1
4 Max jog sets 0 .. 20 0
5 Feeder type 0 = MULT.
1 = SINGLE
0
6 Delay check (milliseconds) 0 .. 60000 0
Example
Command Answer Description
S01; Select unit 1
LIW?; 100,100,1,0,0,0 CRLF Query general setpoint parameters
LIW200,100,5,0,0,0; 0 CRLF Change to: 200ms jog on, 100ms jog off, 5 jogs in a set,
unlimited sets, multiple feeders, no check delay.
TDD1; 0 CRLF Save setting
21.3.31 LWN: Span Calibration
Calibrate the span of the scale. This is the new form of the LWT; command (see Section 21.3.33). Because
the C500 series has no concept of normal and direct calibration mode, it was necessary to introduce a new
command.
Note
There are two different methods of calibration. Either calibrate with standard
weight or direct input of mV/V.
General
No. of parameters 2
Save changes With TDD1
Increment Trade Counter Yes
Parameter Details
Parameter Description Range Default
1 Span signal in deci-micro volts
per volt.
10000duV/V = 1000uV/V =
1 mV/V
-50000 .. 50000 -
2 Status (see table below) 0 .. 106 -
Calibration Status
Status value Description
0 Calibration finished successfully
1 Calibration in process (busy)
104 Error span too high (> 5.0 mV/V) or too low (< -5.0 mV/V). Calibration aborted.
106 Other calibration error. Calibration aborted.
Example: Normal Calibration with Weight
142 C500-600-2.0.3
