21.3.39 POR: External IO
Force digital outputs on or off. This is only enabled for IO lines not configured as setpoints. POR? replies with
the status of the 8 digital IO lines.
General
No. of parameters 8
Save changes With TDD1
Increment Trade Counter No
Parameter Details
Parameter Description Range Default
1 - 8 Output 1 - 8 0 or 1 -
Example
Command Answer Description
S01; Select unit 1
POR1,1,1,1,1,1,1,1; 0 CRLF IO 1 - 8 set as outputs and set to on
TDD1; 0 CRLF Save setting
LIV1,1; 0 CRLF Setpoint 1 is active
POR1,1,1,1; ? CRLF Not possible as POR not enabled for setpoint 1
POR,1,1,1; 0 CRLF Ok, only deactivated setpoint changed
POR?; 1,1,1,1,0,0,0,0 CRLF IO 1 - 4 are on, IO 5 - 8 are off
21.3.40 PRS: Print and Automatic Output Settings
General
No. of parameters 10
Save changes With TDD1
Increment Trade Counter No
Parameter Details
148 C500-600-2.0.3
