No. of parameters 1
Save changes -
Increment Trade Counter No
Parameter Details
Parameter Description Range Default
1 Current signal in deci-micro volts per volt.
10000duV/V = 1000uV/V = 1 mV/V
-50000 .. 50000 -
Example
Command Answer Description
S01; Select unit 1
VAL?; 5076 CRLF Current reading is 0.5076 mV/V
21.3.55 WFP: Which serial port is this
Determine which serial port this connection is on.
General
No. of parameters 1
Save changes -
Increment Trade Counter No
Parameter Details
Parameter Description Range Default
1 Port 0 = Module 1 Port A
1 = Module 1 Port B
2 = Module 2 Port A
3 = Module 2 Port B
4 = TCP Network Port
5 = TCP Auto Port
6 = USB Slave Port
7 = USB Host Serial Port
8 = USB Line Printer
9 = Front optical rinlink
10 = Rear optical rinlink / Onboard serial 1
11 = UDP Outgoing Port 1
12 = UDP Outgoing Port 2
13 = UDP Incoming Port 1
14 = UDP Incoming Port 2
17 = Onboard serial 2
N/A
Example
Command Answer Description
S01; Select unit 1
WFP?; 4 CRLF Connected to the TCP network port (usually TCP port 2222)
WFP?; 0 CRLF Connected to serial module 1, port A
21.3.56 WMD: Weighing Mode
Set the weighting mode of the instrument. This selects between single range, dual range and dual interval
weighing modes.
General
158 C500-600-2.0.3
