Name Address Type R W Description
Reg instrument begin 032D
H
execute N A Stop all streaming, clear the lua display,
flush the keys, and take control of event,
printer, and serial devices.
Setpoint Status 032E
H
uint32 A N 32 bit number. Lower 16 bits are setpoint
status, upper 16 bits are inverted from the
lower 16.
Heartbeat 032F
H
uint8 A A Timeout (in seconds, accurate to ± 1
seconds) until the display and keyboard is
handed back to the C500. Executing this
register cleans up immediately.
Lua Stream Set 1 Data 0340
H
stream A A Returns a block of data which is selected
in Stream Register 1-5.
Use a read command to read a single set of
data.
Use an execute command (with a
parameter of 1) to switch on automatic
transmition at the mode speed.
Lua Stream Set 1 Mode 0341
H
uint8 A A 0: Manual - read ‘Stream Data’ register
1: Auto Sync - Data is sent at sync
freqency
2: Auto 10Hz - Data is sent at 10Hz
3: Auto 5Hz - Data is sent at 5Hz
4: Auto 1Hz - Data is sent at 1Hz
Lua Stream Set 1: Register 0 0342
H
register A A Register to stream
Lua Stream Set 1: Register 1 0343
H
register A A Register to stream
Lua Stream Set 1: Register 2 0344
H
register A A Register to stream
Lua Stream Set 1: Register 3 0345
H
register A A Register to stream
Lua Stream Set 1: Register 4 0346
H
register A A Register to stream
Lua Stream Set 2 Data 0350
H
stream A A Returns a block of data which is selected
in Stream Register 1-5.
Use a read command to read a single set of
data.
Use an execute command (with a
parameter of 1) to switch on automatic
transmition at the mode speed.
Lua Stream Set 2 Mode 0351
H
uint8 A A 0: Manual - read ‘Stream Data’ register
1: Auto Sync - Data is sent at sync
freqency
2: Auto 10Hz - Data is sent at 10Hz
3: Auto 5Hz - Data is sent at 5Hz
4: Auto 1Hz - Data is sent at 1Hz
Lua Stream Set 2: Register 0 0352
H
register A A Register to stream
Lua Stream Set 2: Register 1 0353
H
register A A Register to stream
Lua Stream Set 2: Register 2 0354
H
register A A Register to stream
Lua Stream Set 2: Register 3 0355
H
register A A Register to stream
Lua Stream Set 2: Register 4 0356
H
register A A Register to stream
Eject USB 0370
H
execute N A Execute register to safely eject USB
USB Partition Notification 0371
H
string A N When the Luastatus2 USB Notification bit
is set high, this should be read to
determine what USB partition event has
occurred.
