Rion VA-12 User Manual

45
Measurement in Time Waveform Mode
X axis zoom factor
Shows the X axis zoom factor for the currently displayed graph. The
following settings are available.
• Number of analysis lines is 3200: ×1, ×2, ×4, ×8, ×16, ×32
• Number of analysis lines is 1600: ×1, ×2, ×4, ×8, ×16
• Number of analysis lines is 800: ×1, ×2, ×4, ×8
• Number of analysis lines is 400: ×1, ×2, ×4
• Number of analysis lines is 200: ×1, ×2
X axis unit
Shows “ms”.
X axis upper limit
Shows the upper limit value of the X axis for the current display range.
Magnifying glass symbol
This appears in display scaling mode. The SCALE ON/OFF key is used
to switch the mode on and off. For details, see page 51.
Graph zoom symbol or cursor move symbol
These appear in display scaling mode (see page 51) and show the function
of the / / / keys. When the graph zoom symbol is shown, the
/ / / keys serve to change the zoom factor. When the cursor move
symbol is shown, the / keys serve to move the cursor.
The SCALE EXPAND/MOVE key is used to switch between the graph
zoom symbol and the cursor move symbol .
X axis lower limit
Shows the lower limit value of the X axis for the current display range.
Y axis lower limit
Shows the lower limit value of the Y axis for the current display range.
