Measurement in Time Waveform Mode
Cursor value readout
This shows the value at the marker symbol on the cursor. The left value
is for the X axis and the right value for the Y axis.
Cursor
The cursor can be moved right and left with the / keys. Holding down
a key will move the cursor faster. If the cursor is shown as a broken line,
it cannot be moved (see page 52).
Y axis unit
The unit indication changes according to the measurement data type.
• Acceleration: m/s
2
• Velocity: mm/s
• Displacement: mm
• Envelope: No indication
Y axis upper limit
Shows the upper limit value of the Y axis for the current display range.
