126
Serial Interface
The CC-42R serial I/O cable uses a 9-pin connector (female).
The cable is optional.
Note
When VM-55 is connected to a computer, the minimum
measurement level of VM-55 may rise by the noise
from a computer.
Transfer protocol
Transfer principle: full duplex
Sync principle: asynchronous
Baud rate: 9600 / 19200 / 38400 / 57600 / 115200 bps
Data word length: 8 bit
Stop bits: 1 bit
Parity check: none
Flow control: X parameter
Shield
VM-55
I/O connector
Computer
