Preparations
Vibration level meter settings when using a printer
When using a printer, perform the following steps to set the baud rate for the
vibration level meter.
1. Press the MENU/ENTER key to bring up the menu list screen.
2. Use the
keys to select [Display / I/O] and press the
MENU/ENTER key. The display / I/O screen appears.
3. Use the
keys to select [Communication Interface] and press the
MENU/ENTER key. The communication control function screen appears.
4. Use the
keys to select [RS-232C] and press the MENU/ENTER key.
5. Use the
keys to select [Baud rate] on the display / I/O screen and
press the MENU/ENTER key. The baud rate screen appears.
6. Set the baud rate according to the printer in use.
For DPU-414: Use the keys to select [19200bps] and press the
MENU/ENTER key.
For BL2-58: Use the keys to select the same baud rate as set
at the BL2-58 and press the MENU/ENTER key (see
page 28).
7. Press the START/STOP key to return to the measurement screen.
