45
Reading the Display
Mode of analysis
Indicates the condition of the display screen.
Measurement time/Total measurement time
When the store mode is Manual, the measurement time is displayed.
When the store mode is Auto, the total measurement time is displayed
(see page 82, 88).
Comparator indication
Appears when the comparator function is being used (see page 38).
Operation/measurement elapsed time
Shows the elapsed time from the start of measurement.
SD memory card insertion indicator
Shown when an SD memory card is inserted in the unit (see page 24).
SD memory card remaining capacity
Shows the remaining capacity of an inserted SD memory card.
Note
Even when a new SD memory card is inserted, the
remaining capacity may sometimes be shown as 99%
rather than 100%.
L
v
store interval
When the store mode is Auto or Timer Auto, the L
v
store interval is displayed
(see page 88, 94).
Current date and time
Shows the current date and time.
L
eq
calculation interval
When the store mode is Auto or Timer Auto, the L
eq
calculation interval
is displayed (see page 89, 94).
Setting of output, etc
The selected output signal on the [OUTPUT] of the [Display / I/O] screen
is shown here (see page 62).
To Next Page
