63
Reading the Display
Comparator
Displays the screen to set the comparator signal output (open collector
output can be used to control external equipment) from the I/O connector
of the unit.
Select [Comparator] and press the MENU/ENTER key. The comparator
screen appears (see page 38).
Note
When the optional Extended Function Program
VX-55EX is not installed, the comparator cannot
be selected.
Communication Interface
Displays the screen to select a type of communication with a computer
or printer to be connected to the unit.
Select [Communication Interface] and press the MENU/ENTER key. The
communication interface screen appears.
Use the keys to select the communication type (OFF, USB, RS-232C)
and press the MENU/ENTER key.
Baud rate
Displays the screen to select the baud rate value when [Communication
Interface] is set to “RS-232C”.
Select [Baud rate] and press the MENU/ENTER key. The baud rate screen
appears.
Use the keys to select the baud rate value (9600bps, 19200bps,
38400bps, 57600bps, 115200bps) and press the MENU/ENTER key.
Flow control
Displays the screen to select the baud rate value when [Communication
Interface] is set to “RS-232C”.
Select [Flow control] and press the MENU/ENTER key. The  ow control
screen appears.
Use the keys to select the  ow control type (OFF, HARD, SOFT)
and press the MENU/ENTER key
